CLW5250JSQD4 Detail - Suizhou Liyuan Trading Co., Ltd
Detailed parameters
CLW5250JSQD4  Model technical parameters
Name: CLW5250JSQD4 Exterior size(mm): 11950,10980×2500×3900
Chassis: DFL1250A12 Container size(mm): 8300,8400,7300,7400×2294×800,550
Total weight :(kg) 25000 Approach angle/ Departure angle(° ) 20/11,20/10,20/14,20/13
Payload:(kg) 9135,9935,9200,10000 Front suspension/rear suspension(mm): 1460/3440,1460/3490,1460/2820,1460/2870
Kerb Mass:(kg) 15670,14870(Kg) Max Speed(km/h): 85
Chassis parameters
Chassis: DFL1250A12 Axle weight: 7000/18000(并装双轴)
Number of axles: 3 Fuel Type: Diesel fuel
Wheelbase(mm): 5350+1300,5350+1350,5700+1300,5700+1350 Fronttread(mm): 1986,2040
Max people in cab: 3,2 Rear tread(mm): 1860/1860
Number of tires: 10 Number of spring axle: 8/9,8/10,9/10
Tire Type: 10.00-20 18PR,10.00R20 18PR,11.00-20 18PR,11.00R20 16PR,295/80R22.5 16PR
introduction: 一:上装随车起重机参数(起重机型号/起重机质量(kg)/最大起升载荷(kg))对应为:SQ10S/3500/10000,SQ8S/2700/8000。二:轴距(mm)/整车长度(mm)/货箱内长度(mm)/整备质量(kg)/后悬(mm)对应为:5350+1300,5350+1350/10980/7300,7400/14870/2870,2820;5700+1300,5700+1350/11950/8300,8400/15670/3490,3440。三:驾驶室准乘人数3人时对应额定载质量(kg)9135,9935,驾驶室准乘人数2人时对应额定载质量(kg)9200,10000。四:防护材料:Q235A碳钢,连接方式:左右侧面及后下部防护均采用焊接连接,后部防护断面尺寸(mm):100×50,后部防护离地高度(mm):520。五:随底盘选装驾驶室。该车安装带有卫星定位功能的行驶记录仪。ABS生产厂家:东风电子科技股份有限公司制动系统公司;型号:3631010-C2000。
Engine parameters
Type Manufacturer Displacement(ml) Power(kw)
ISDe245 40
ISDe270 40
ISC8.3-245E40A
ISC8.3-270E40A
ISC8.3-292E40A
东风康明斯发动机有限公司
东风康明斯发动机有限公司
东风康明斯发动机有限公司
东风康明斯发动机有限公司
东风康明斯发动机有限公司
6700
6700
8300
8300
8300
180
198
180
198
215
other parameters
Introduction:
more Picture:
※ Need more information or pictures?please contact us and we will provide best service!。
