CSC5121GXEE4 - Suizhou Liyuan Trading Co., Ltd
  • Phone:Mr zhou +86 15997916929
  • Add time:2011-07-08 11:15:17
  • Hits:190
for the convenience of users to mention cars, our company agents to carry out car door-to-door delivery service.
the above price of vehicles, models, such as configuration and the color difference, please in order to prevail.
.
CSC5121GXEE4 Detail - Suizhou Liyuan Trading Co., Ltd
Detailed parameters
CSC5121GXEE4  Model technical parameters
Name: CSC5121GXEE4 Exterior size(mm): 7400,7650×2480×2950
Chassis: EQ1121GKJ2 Container size(mm): ××
Total weight :(kg) 12450 Approach angle/ Departure angle(° ) 30/28
Payload:(kg) 6300 Front suspension/rear suspension(mm): 1250/2200
Kerb Mass:(kg) 5955(Kg) Max Speed(km/h): 90
Chassis parameters
Chassis: EQ1121GKJ2 Axle weight: 4750/7700
Number of axles: 2 Fuel Type: Diesel fuel
Wheelbase(mm): 3950,4200 Fronttread(mm): 1900,1810
Max people in cab: 3 Rear tread(mm): 1800
Number of tires: 6 Number of spring axle: 8/11+8
Tire Type: 9.00-20 14PR,9.00R20 14PR
introduction: 运输介质:液态污物,密度:800千克/立方米。罐体有效容积8.2立方米。罐体外形尺寸(mm)长×宽×高:4500×2000×1350,4750×1940×1320;外形长/轴距/罐体尺寸对应关系为(mm):7400/3950/4500×2000×1350,7650/4200/4750×1940×1320。侧防护采用冷弯型钢/Q235B,螺栓连接;后防护采用冷弯型钢/Q235B,焊接连接。后防护截面尺寸200mm×50mm,下边缘离地高度500mm。随底盘选装驾驶室。ABS型号为3631010-C2000,生产厂家为东风电子科技股份有限公司制动系统公。
Engine parameters
Type Manufacturer Displacement(ml) Power(kw)
YC4E160-42
ISDe160 40
ISB170 40
YC6J160-46
广西玉柴机器股份有限公司
东风康明斯发动机有限公司
东风康明斯发动机有限公司
广西玉柴机器股份有限公司
4260
4500
5900
6494
118
118
125
118
other parameters
Introduction:
more Picture:
※ Need more information or pictures?please contact us and we will provide best service!。
