hcq5111gxwe5 Model technical parameters | |||
Name: | hcq5111gxwe5 | Exterior size(mm): | 6850×2300×2850,2950 |
Chassis: | EQ1110SJ8BDC | Container size(mm): | ×× |
Total weight :(kg) | 11450 | Approach angle/ Departure angle(° ) | 20/12 |
Payload:(kg) | 5870 | Front suspension/rear suspension(mm): | 1130/1920,1150/1900 |
Kerb Mass:(kg) | 5385(Kg) | Max Speed(km/h): | 103 |
Chassis parameters | |||
Chassis: | EQ1110SJ8BDC | Axle weight: | 4360/7090 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3800 | Fronttread(mm): | 1745 |
Max people in cab: | 3 | Rear tread(mm): | 1620 |
Number of tires: | 6 | Number of spring axle: | 8/10+7 |
Tire Type: | 8.25R20 14PR,245/70R19.5 | ||
introduction: | 罐体有效容积7.70立方米,运输介质:液态污物,密度:800千克/每立方米.罐体长直段长4100mm,短轴1550mm.侧防护材料为Q235,联接方式为连接支架固焊在付车架大梁上.后防护材料为Q235,连接方式:用结构连接件固焊在主车后端,后部防护装置断面尺寸(宽×高)60×120(mm),后部防护离地高度:490mm.随底盘选装驾驶室.选装罐体结构;ABS系统生产厂家,型号 :襄阳东风隆诚机械有限责任公司,ABS/ASR-24V-4S/4M。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
CY4SK251 YC4S150-50 ISF3.8s5154 4DX23-140E5 YN38CRE1 YC4Y22-15050 |
东风朝阳朝柴动力有限公司 广西玉柴机器股份有限公司 北京福田康明斯发动机有限公司 一汽解放汽车有限公司无锡柴油机厂 昆明云内动力股份有限公司 广西玉柴机器股份有限公司 |
3856 3767 3760 3857 3760 2169 |
115 110 115 105 95 110 |
other parameters |
Introduction: |
more Picture: |
※ Need more information or pictures?please contact us and we will provide best service!。 |
