CLW5101JGKT4 - Suizhou Liyuan Trading Co., Ltd
  • Phone:Mr zhou +86 15997916929
  • Add time:2011-07-08 11:15:17
  • Hits:175
for the convenience of users to mention cars, our company agents to carry out car door-to-door delivery service.
the above price of vehicles, models, such as configuration and the color difference, please in order to prevail.
.
CLW5101JGKT4 Detail - Suizhou Liyuan Trading Co., Ltd
Detailed parameters
CLW5101JGKT4  Model technical parameters
Name: CLW5101JGKT4 Exterior size(mm): 9200,8530×2480×3610
Chassis: EQ1168VFJ1 Container size(mm): ××
Total weight :(kg) 10080 Approach angle/ Departure angle(° ) 23/14,20/14,23/13,20/13
Payload:(kg) Front suspension/rear suspension(mm): 1250/2050,1450/2050,1250/2130,1450/2130
Kerb Mass:(kg) 9885(Kg) Max Speed(km/h): 90
Chassis parameters
Chassis: EQ1168VFJ1 Axle weight: 3320/6760
Number of axles: 2 Fuel Type: Diesel fuel
Wheelbase(mm): 3800,3950,4200,4500,4700,5100 Fronttread(mm): 1920,1960
Max people in cab: 3 Rear tread(mm): 1860
Number of tires: 6 Number of spring axle: 9/10+8
Tire Type: 9.00-20,9.00R20,10.00-20,10.00R20
introduction: 该车吊臂前伸为1200mm; 整车长(mm)/轴距(mm) /前悬(mm)/ 后悬(mm)/接近角(°)/ 离去角(°)对应为:9200/4700/1250/2050/23/14, 8530/3950/1250/2130/23/13。随底盘选装新款驾驶室时; 该车吊臂前伸为1000mm, 整车长(mm)/轴距(mm) /前悬(mm)/ 后悬(mm)/接近角(°)/ 离去角(°)对应为:9200/4700/1450/2050/20/14, 8530/3950/1450/2130/20/13。防护材料:Q235A碳钢,连接方式:左右侧面与副梁、侧围板焊接连接,后下部防护与车架采用焊接连接,后部防护断面尺寸(mm):100×50×5,后部防护离地高度(mm):480。
Engine parameters
Type Manufacturer Displacement(ml) Power(kw)
YC6J180-46
YC6J160-46
ISB170 40
ISB190 40
YC4E160-46
广西玉柴机器股份有限公司
广西玉柴机器股份有限公司
东风康明斯发动机有限公司
东风康明斯发动机有限公司
广西玉柴机器股份有限公司
6494
6494
5900
5900
4260
132
118
125
140
118
other parameters
Introduction:
more Picture:
※ Need more information or pictures?please contact us and we will provide best service!。
