CLW5160GXET4 - Suizhou Liyuan Trading Co., Ltd
  • Phone:Mr zhou +86 15997916929
  • Add time:2011-07-08 11:15:17
  • Hits:141
for the convenience of users to mention cars, our company agents to carry out car door-to-door delivery service.
the above price of vehicles, models, such as configuration and the color difference, please in order to prevail.
.
CLW5160GXET4 Detail - Suizhou Liyuan Trading Co., Ltd
Detailed parameters
CLW5160GXET4  Model technical parameters
Name: CLW5160GXET4 Exterior size(mm): 8090,7890,7600,7800×2470×3180
Chassis: EQ1168VFJ1 Container size(mm): ××
Total weight :(kg) 15900 Approach angle/ Departure angle(° ) 23/14,20/14
Payload:(kg) 7780 Front suspension/rear suspension(mm): 1250/2140,1450/2140,1250/2400,1450/2400
Kerb Mass:(kg) 7925(Kg) Max Speed(km/h): 90
Chassis parameters
Chassis: EQ1168VFJ1 Axle weight: 5950/9950
Number of axles: 2 Fuel Type: Diesel fuel
Wheelbase(mm): 3800,3950,4200,4500,4700,5100 Fronttread(mm): 1920,1960
Max people in cab: 3 Rear tread(mm): 1860
Number of tires: 6 Number of spring axle: 9/10+8
Tire Type: 9.00-20,9.00R20,10.00-20,10.00R20
introduction: 选装新款驾驶室时,前悬(mm) :1450,接近角(°) :20。罐体有效容积:9.0立方米,介质:液态污物和粪便,密度:0.9吨/立方米; 罐体外形尺寸(长×长轴×短轴)(mm)/整车长(mm)/轴距(mm)/ 前悬(mm)对应关系为: 4800×2100×1350/7890(8090)/4500/1250(1450) ; 罐体外形尺寸(长×长轴×短轴)(mm)/整车长(mm)/轴距(mm)/前悬(mm):对应关系为:4300×2300×1400/7600(7800)/3950/1250(1450);防护材料:Q235A碳钢,连接方式:左右侧面及后下部防护均采用焊接连接,后部防护断面尺寸(mm):100×50×5,后部防护离地高度(mm):450。ABS的型号:4S/4M,生产厂家:威伯科汽车控制系统中国有限公司。
Engine parameters
Type Manufacturer Displacement(ml) Power(kw)
YC6J180-46
YC6J160-46
ISB170 40
ISB190 40
YC4E160-46
广西玉柴机器股份有限公司
广西玉柴机器股份有限公司
东风康明斯发动机有限公司
东风康明斯发动机有限公司
广西玉柴机器股份有限公司
6494
6494
5900
5900
4260
132
118
125
140
118
other parameters
Introduction:
more Picture:
※ Need more information or pictures?please contact us and we will provide best service!。
